Vacon 100 flow Applications Manual page 96

VACON · 96
CHANGING THE CONTROL PLACE
1 Anywhere in the menu structure, push the FUNCT
button.
2 To make a selection of the Local/Remote, use the
arrow buttons Up and Down. Push the OK button.
3 To make a selection of Local or Remote, use the
arrow buttons Up and Down again. To accept the
selection, push the OK button.
4 If you changed Remote control place to Local, that
is, the keypad, give a keypad reference.
After the selection, the display goes back into the same location where it was when you
pushed the FUNCT button.
3
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
USER INTERFACES
READY
STOP
Main Menu
ID: M1
Monitor
( 12 )
Parameters
( 21 )
Diagnostics
( 6 )
READY
STOP
Choose action
ID:1805
Change direction
Control page
Local/Remote
STOP READY
Local/Remote
ID:211
Local
Remote
READY
STOP
Main Menu
ID: M1
Monitor
( 12 )
Parameters
( 21 )
Diagnostics
( 6 )
Keypad
Keypad
Keypad
I/O
