VACON · 242 PARAMETER DESCRIPTIONS
P3.3.3.3 PRESET FREQUENCY 1 (ID 105)
Use this parameter to set the preset frequency reference when the preset frequencies
function is used.
Select the preset frequencies with the digital input signals.
P3.3.3.4 PRESET FREQUENCY 2 (ID 106)
Use this parameter to set the preset frequency reference when the preset frequencies
function is used.
Select the preset frequencies with the digital input signals.
P3.3.3.5 PRESET FREQUENCY 3 (ID 126)
Use this parameter to set the preset frequency reference when the preset frequencies
function is used.
Select the preset frequencies with the digital input signals.
P3.3.3.6 PRESET FREQUENCY 4 (ID 127)
Use this parameter to set the preset frequency reference when the preset frequencies
function is used.
Select the preset frequencies with the digital input signals.
P3.3.3.7 PRESET FREQUENCY 5 (ID 128)
Use this parameter to set the preset frequency reference when the preset frequencies
function is used.
Select the preset frequencies with the digital input signals.
P3.3.3.8 PRESET FREQUENCY 6 (ID 129)
Use this parameter to set the preset frequency reference when the preset frequencies
function is used.
Select the preset frequencies with the digital input signals.
P3.3.3.9 PRESET FREQUENCY 7 (ID 130)
Use this parameter to set the preset frequency reference when the preset frequencies
function is used.
Select the preset frequencies with the digital input signals.
VALUE 0 SELECTED FOR PARAMETER P3.3.3.1:
To set Preset Frequency 0 as reference, set the value 0 Preset Frequency 0 for P3.3.1.5 (I/O
Control Reference A Selection).
To make a selection of a preset frequency between 1 and 7, give digital inputs to P3.3.3.10
(Preset Frequency Selection 0), P3.3.3.11 (Preset Frequency Selection 1), and/or P3.3.3.12
(Preset Frequency Selection 2). The different sets of active digital inputs determine the
preset frequency. You can find more data in the table below. The values of the preset
frequencies stay automatically between the minimum and maximum frequencies (P3.3.1.1
and P3.3.1.2).
