Vacon 100 flow Applications Manual page 260

VACON · 260
10.6.1.3 Descriptions of signal sources
Source
Slot0.#
SlotA.#
SlotB.#
SlotC.#
SlotD.#
SlotE.#
TimeChannel.#
FieldbusCW.#
FieldbusPD.#
10
Function
Digital inputs:
You can use this function to set a digital signal to be in a constant OPEN
or CLOSED state. The manufacturer set some signals so that they are
always in the CLOSED state, for example parameter P3.5.1.15 (Run Ena-
ble). The Run Enable signal is always on if you do not change it.
# = 1: Always OPEN
# = 2-10: Always CLOSED
Analogue inputs (used for test purposes):
# = 1: Analogue input = 0% of the signal strength
# = 2: Analogue input = 20% of the signal strength
# = 3: Analogue input = 30% of the signal strength etc.
# = 10: Analogue input = 100% of the signal strength
Number (#) agrees to a digital input in slot A.
Number (#) agrees to a digital input in slot B.
Number (#) agrees to a digital input in slot C.
Number (#) agrees to a digital input in slot D.
Number (#) agrees to a digital input in slot E.
1=Time Channel1, 2=Time Channel2, 3=Time Channel3
Number (#) refers to a control word bit number.
Number (#) refers to the process data 1 bit number.
