Vacon 100 flow Applications Manual page 145

PARAMETERS MENU
Table 50: Digital output settings on standard I/O board, Slot B
Index Parameter
P3.5.3.2.1 RO1 Function
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
Min Max Unit
0 74
Default ID Description
26 = Time channel 2
27 = Time channel 3
28 = FB ControlWord
B13
29 = FB ControlWord
B14
30 = FB ControlWord
B15
31 = FB Process-
Data1.B0
32 = FB Process-
Data1.B1
33 = FB Process-
Data1.B2
34 = Maintenance
alarm
35 = Maintenance fault
36 = Block 1 Out
37 = Block 2 Out
38 = Block 3 Out
39 = Block 4 Out
40 = Block 5 Out
Varies 11001 41 = Block 6 Out
42 = Block 7 Out
43 = Block 8 Out
44 = Block 9 Out
45 = Block 10 Out
46 = Jockey pump con-
trol
47 = Priming pump
control
48 = Auto-cleaning
active
49 = Multi-pump K1
control
50 = Multi-pump K2
control
51 = Multi-pump K3
control
52 = Multi-pump K4
control
53 = Multi-pump K5
control
54 = Multi-pump K6
control
VACON · 145
5
