VACON · 90
3
USER INTERFACES
3.1
NAVIGATION ON THE KEYPAD
The data of the AC drive is in menus and submenus. To move between the menus, use the
arrow buttons Up and Down in the keypad. To go into a group or an item, push the OK button.
To go back to the level where you were before, push the Back/Reset button.
On the display, you see your current location in the menu, for example M3.2.1. You also see
the name of the group or item in your current location.
3
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
USER INTERFACES
