I/O AND HARDWARE MENU
Table 111: Power unit settings
Index Parameter
P5.6.1.1 Fan Control Mode
P5.6.4.1 Sine Filter
P5.6.5.1 Harmonic Filter
7.5

KEYPAD

Table 112: The keypad parameters in the I/O and Hardware menu
Index Parameter
P5.7.1 Timeout Time
P5.7.2 Default Page
P5.7.3 Menu Index
P5.7.4 Contrast **
P5.7.5 Backlight Time
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
Min Max Unit
0 1
0 1
0 1
Min Max Unit
0 60 min
0 4
30 70 %
0 60 min
Default ID Description
0 = Always on
1 2377
1 = Optimised
0 = Not used
0 2527
1 = In use
0 = Not used
0 2497
1 = In use
Default ID Description
The time after which
the display goes back
to the page that is set
0 * with parameter P5.7.2.
0 = Not used
The page that the dis-
play shows when the
drive is powered up, or
when the time that is
set with P5.7.1 goes. If
the value is set to 0,
the display shows the
last page that it
0 *
showed.
0 = None
1 = Enter menu index
2 = Main menu
3 = Control page
4 = Multimonitor
Set a page to be the
menu index. (The
selection 1 in P5.7.2.)
Set the contrast of the
50
display (30-70%).
Set the time after
which the backlight of
the display goes out
5
(0-60 min). If the value
is set to 0, the back-
light is always on.
