PID CONTROLLER

V2.8.1 PID SETPOINT (ID 20)
This monitoring value shows the value of the PID setpoint signal in process units.
You can use the parameter P3.13.1.7 to select the process unit (See 10.14.1 Basic settings).
V2.8.2 PID FEEDBACK (ID 21)
This monitoring value shows the value of the PID feedback signal in process units.
You can use the parameter P3.13.1.7 to select the process unit (See 10.14.1 Basic settings).
V2.8.3 PID FEEDBACK (1) (ID 15541)
This monitoring value shows the value of the PID feedback signal 1 in process units.
V2.8.4 PID FEEDBACK (2) (ID 15542)
This monitoring value shows the value of the PID feedback signal 2 in process units.
V2.8.5 PID ERROR (ID 22)
This monitoring value shows the error value of the PID controller.
V2.8.6 PID OUTPUT (ID 23)
This monitoring value shows the output of the PID controller as a percentage (0-100%).
V2.8.7 PID STATUS (ID 24)
This monitoring value shows the state of the PID controller.
9.7

EXTERNAL PID CONTROLLER

V2.9.1 EXTPID SETPOINT (ID 83)
This monitoring value shows the value of the PID setpoint signal in process units.
You can use the parameter P3.14.1.10 to select the process unit (See 10.14.1 Basic settings).
V2.9.2 EXTPID FEEDBACK (ID 84)
This monitoring value shows the value of the PID feedback signal in process units.
You can use the parameter P3.14.1.10 to select the process unit (See 10.14.1 Basic settings).
V2.9.3 EXTPID ERROR (ID 85)
This monitoring value shows the error value of the PID controller.
The error value is the deviation of PID feedback from the PID setpoint in process unit.
You can use the parameter P3.14.1.10 to select the process unit (See 10.14.1 Basic settings).
