GROUP 3.9: PROTECTIONS

Table 56: General protections settings
Index Parameter
Response to External
P3.9.1.2
Fault
P3.9.1.3 Input Phase Fault
P3.9.1.4 Undervoltage Fault
Response to Output
P3.9.1.5
Phase Fault
Response to Field-
P3.9.1.6 bus Communication
Fault
Slot Communication
P3.9.1.7
Fault
P3.9.1.8 Thermistor Fault
P3.9.1.9 PID Soft Fill Fault
Response to PID
P3.9.1.10
Supervision Fault
Response to External
P3.9.1.11 PID Supervision
Fault
Preset Alarm Fre-
P3.9.1.13
quency
Response to Safe
P3.9.1.14 Torque Off (STO)
Fault
5
Min Max Unit
0 3
0 1
0 1
0 3
0 4
0 3
0 3
0 3
0 3
0 3
P3.3.1.1 P3.3.1.2 Hz
0 2
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
PARAMETERS MENU
Default ID Description
0 = No action
1 = Alarm
2 = Fault (Stop accord-
2 701
ing to stop function)
3 = Fault (Stop by
coasting)
0 = 3-phase support
0 730
1 = 1-phase support
0 = Fault stored in his-
tory
0 727
1 = Fault not stored in
history
2 702
0 = No action
1 = Alarm
2 = Alarm + preset fault
frequency (P3.9.1.13)
3 733
3 = Fault (Stop accord-
ing to stop function)
4 = Fault (Stop by
coasting)
2 734
0 732
2 748
2 749
2 757
25.00 183
0 = No action
1 = Alarm
2 775
2 = Fault (Stop by
coasting)
