VACON · 84
Set a value for P3.15.7 Autochanged pumps
29
Step 30 shows only if you set the value Enabled (Interval) to parameter Autochange in step 28.
30 Set a value for P3.15.8 Autochange Interval
Steps 31 and 32 show only if you set the value Enabled (Weekdays) to parameter Autochange
in step 28.
31 Set a value for P3.15.9 Autochange Days
32 Set a value for P3.15.10 Autochange Time of Day
Set a value for P3.15.11 Autochange Frequency
33
Limit
34 Set a value for P3.15.12 Autochange Pump Limit
35 Set a value for P3.15.13 Bandwidth
Set a value for P3.15.14 Bandwidth Delay
36
The Multi-pump (single drive) application wizard is completed.
2.5

MULTI-PUMP (MULTIDRIVE) APPLICATION WIZARD

The application wizard helps you to set the basic parameters that are related to the
application.
To start the Multi-pump (multidrive) application wizard, set the value Multi-pump (Multidrive)
to parameter P1.2 Application (ID 212) in the keypad.
NOTE!
If you start the application wizard from the Startup wizard, the wizard goes directly
to step 11.
2
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
0 = Auxiliary pumps
1 = All pumps
Range: 0-3000 h
Range: Monday to Sunday
Range: 00:00:00 to 23:59:59
Range: P3.3.1.1-P3.3.1.2 Hz
Range: 1-8
Range: 0-100%
Range: 0-3600 s
WIZARDS
