PARAMETERS MENU
5.11

GROUP 3.11: APPLICATION SETTINGS

Table 65: Application settings
Index Parameter
P3.11.1 Password
P3.11.2 C/F Selection
P3.11.3 kW/hp Selection
P3.11.4 Multimonitor View
5.12

GROUP 3.12: TIMER FUNCTIONS

Table 66: Interval 1
Index Parameter
P3.12.1.1 ON Time
P3.12.1.2 OFF Time
P3.12.1.3 Days
P3.12.1.4 Assign to Channel
Table 67: Interval 2
Index Parameter
P3.12.2.1 ON Time
P3.12.2.2 OFF Time
P3.12.2.3 Days
P3.12.2.4 Assign to Channel
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
Min Max Unit
0 9999
0 1
0 1
0 2
Min Max Unit
hh:mm:
00:00:00 23:59:59
ss
hh:mm:
00:00:00 23:59:59
ss
Min Max Unit
hh:mm:
00:00:00 23:59:59
ss
hh:mm:
00:00:00 23:59:59
ss
Default ID Description
0 1806
0 = Celsius
0 * 1197
1 = Fahrenheit
0 = kW
0 1198
1 = hp
0 = 2x2 sections
1 1196 1 = 3x2 sections
2 = 3x3 sections
Default ID Description
00:00:00 1464
00:00:00 1465
B0 = Sunday
B1 = Monday
B2 = Tuesday
1466 B3 = Wednesday
B4 = Thursday
B5 = Friday
B6 = Saturday
B0 = Time channel 1
1468 B1 = Time channel 2
B2 = Time channel 3
Default ID Description
See Interval 1.
00:00:00 1469
See Interval 1.
00:00:00 1470
1471 See Interval 1.
1473 See Interval 1.
VACON · 159
