WIZARDS
Set a value for parameters P3.17.4 Fire Mode Acti-
4 vation on OPEN / P3.17.5 Fire Mode Activation on
CLOSE
Set a value for parameter P3.17.6 Fire Mode
Reverse
5
Set a value for P3.17.1 Fire Mode Password
6
The Fire mode wizard is completed.
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
Make a selection of a digital input to activate
Fire mode. See also Chapter 10.6.1 Program-
ming of digital and analogue inputs.
Make a selection of a digital input to activate
the reverse direction in Fire mode.
DigIn Slot0.1 = FORWARD
DigIn Slot0.2 = REVERSE
Set a password to enable the Fire mode func-
tion.
1234 = Enable test mode
1002 = Enable Fire mode
