Vacon 100 flow Applications Manual page 144

VACON · 144
Table 50: Digital output settings on standard I/O board, Slot B
Index Parameter
P3.5.3.2.1 RO1 Function
5
Min Max Unit
0 74
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
PARAMETERS MENU
Default ID Description
The function selection
for R01:
0 = None
1 = Ready
2 = Run
3 = General fault
4 = General fault inver-
ted
5 = General alarm
6 = Reversed
7 = At speed
8 = Thermistor fault
9 = Motor regulator
active
10 = Start signal active
11 = Keypad control
active
12 = I/O B control acti-
vated
Varies 11001 13 = Limit supervision
1
14 = Limit supervision
2
15 = Fire Mode active
16 = Flushing activated
17 = Preset freq. active
18 = Quick stop activa-
ted
19 = PID in Sleep mode
20 = PID soft fill active
21 = PID feedback
supervision (limits)
22 = Ext. PID supervi-
sion (limits)
23 = Input press.
alarm/fault
24 = Frost prot. alarm/
fault
25 = Time channel 1
