Group 3.5: I/O Configuration - Vacon 100 flow Applications Manual

VACON · 138
5.5

GROUP 3.5: I/O CONFIGURATION

Table 43: Digital input settings
Index Parameter
P3.5.1.1 Control Signal 1 A
P3.5.1.2 Control Signal 2 A
P3.5.1.3 Control Signal 3 A
P3.5.1.4 Control Signal 1 B
P3.5.1.5 Control Signal 2 B
P3.5.1.6 Control Signal 3 B
P3.5.1.7 I/O B Control Force
P3.5.1.8 I/O B Reference Force
P3.5.1.9 Fieldbus Control Force
P3.5.1.10 Keypad Control Force
P3.5.1.11 External Fault Close
P3.5.1.12 External Fault Open
P3.5.1.13 Fault Reset Close
P3.5.1.14 Fault Reset Open
P3.5.1.15
P3.5.1.16 Run Interlock 1
P3.5.1.17 Run Interlock 2
P3.5.1.18 Motor Preheat ON
P3.5.1.19 Ramp 2 Selection
P3.5.1.20 Acc/Dec Prohibit
P3.5.1.21 Preset Frequency Selection 0
P3.5.1.22 Preset Frequency Selection 1
5
Default
DigIN SlotA.1 *
DigIN SlotA.2 *
DigIN Slot0.1
DigIN Slot0.1 *
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.1 *
DigIN Slot0.1 *
DigIN Slot0.1 *
DigIN Slot0.1 *
DigIN SlotA.3 *
DigIN Slot0.2
DigIN Slot0.1
Run Enable DigIN Slot0.2
DigIN Slot0.2
DigIN Slot0.2
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.1
DigIN SlotA.4 *
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
ID
403
404
434
423
424
435
425
343
411
410
OPEN = OK
405
CLOSED = External fault
OPEN = External fault
406
CLOSED = OK
Varies 414 CLOSED = Resets all active faults.
213 OPEN = Resets all active faults.
407
OPEN = Start not permitted
1041
CLOSED = Start permitted
1042 As above.
OPEN = No action.
CLOSED = Uses the DC current of the
1044
motor preheat in the Stop state. Used
when the value of P3.18.1 is 2.
OPEN = Ramp 1 Shape, Acceleration
Time 1 and Deceleration Time 1.
408
CLOSED = Ramp 2 Shape, Accelera-
tion Time 2 and Deceleration Time 2.
415
419
Varies 420
PARAMETERS MENU
Description
