Table 12: M1 Quick setup
Index Parameter
1.2 Application
Minimum
1.3 Frequency
Reference
Maximum
1.4 Frequency
Reference
Acceleration
1.5
Time 1
Deceleration
1.6
Time 1
Motor Cur-
1.7
rent Limit
1.8 Motor Type
Motor Nom-
1.9
inal Voltage
1
Min Max
0 4
0.00 P1.4
P1.3 320.0
0.1 3000.0
0.1 3000.0
I *0.1 I
H S
0 2
Varies Varies
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
Unit Default ID
2 212
Hz 0.0 101
50.0 /
Hz 102
60.0
s 5.0 103
s 5.0 104
A Varies 107
0 650
V Varies 110
QUICK STARTUP GUIDE
Description
0 = Standard
1 = HVAC
2 = PID Control
3 = Multi-pump (sin-
gle drive)
4 = Multi-pump
(multidrive)
The minimum fre-
quency reference
that is accepted.
The maximum fre-
quency reference
that is accepted.
Gives the quantity of
time that is neces-
sary for the output
frequency to
increase from 0 fre-
quency to the maxi-
mum frequency.
Gives the quantity of
time that is neces-
sary for the output
frequency to
decrease from the
maximum frequency
to 0 frequency.
The maximum motor
current from the AC
drive.
0 = Induction Motor
1 = Permanent Mag-
net Motor
2 = Reluctance
Motor
Find this value U on
n
the nameplate of the
motor.
NOTE!
Find out if the
motor connection is
Delta or Star.
