PARAMETERS MENU
Table 79: Feedback supervision parameters
Index Parameter
Enable Feedback
P3.13.6.1
Supervision
P3.13.6.2 Upper Limit
P3.13.6.3 Lower Limit
P3.13.6.4 Delay
Response to PID
P3.13.6.5
Supervision Fault
Table 80: Pressure loss compensation parameters
Index Parameter
P3.13.7.1 Enable Setpoint 1
Setpoint 1 Max Com-
P3.13.7.2
pensation
P3.13.7.3 Enable Setpoint 2
Setpoint 2 Max Com-
P3.13.7.4
pensation
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
Min Max Unit
0 1
-99999.9 99999.9
Varies
9 9
-99999.9 99999.9
Varies
9 9
0 30000 s
0 3
Min Max Unit
0 1
-99999.9 99999.9
Varies
9 9
0 1
-99999.9 99999.9
Varies
9 9
Default ID Description
0 = Disabled
0 735
1 = Enabled
Varies 736
Varies 758
0 737
0 = No action
1 = Alarm
2 = Fault (Stop accord-
2 749
ing to stop mode)
3 = Fault (Stop by
coasting)
Default ID Description
0 = Disabled
0 1189
1 = Enabled
0.00 1190
0 1191 See P3.13.7.1.
See P3.13.7.2.
0.00 1192
