PARAMETER DESCRIPTIONS
ID1777: 1 (years)
•
ID1778: 240 (days)
•
ID1779: 2 (hours)
•
ID1780: 18 (minutes)
•
ID1781: 0 (seconds)
•
10.22.5

ENERGY COUNTER

The energy counter counts the total quantity of energy that the drive gets from the supply
network. The counter cannot be reset. To read the value of the counter through fieldbus, use
these ID numbers.
ID 2291 Energy Counter
The value has always 4 digits. The format and the unit of the counter change to agree with
the energy counter value. See the example below.
Example:
0.001 kWh
•
0.010 kWh
•
0.100 kWh
•
1.000 kWh
•
10.00 kWh
•
100.0 kWh
•
1.000 MWh
•
10.00 MWh
•
100.0 MWh
•
1.000 GWh
•
etc...
•
ID2303 Energy Counter Format
The energy counter format gives the position of the decimal point in the value of the Energy
Counter.
40 = 4 digits, 0 fractional digits
•
41 = 4 digits, 1 fractional digit
•
42 = 4 digits, 2 fractional digits
•
43 = 4 digits, 3 fractional digits
•
Example:
0.001 kWh (Format = 43)
•
100.0 kWh (Format = 41)
•
10.00 MWh (Format = 42)
•
ID2305 Energy Counter Unit
The energy counter unit gives the unit for the value of the Energy Counter.
