Vacon 100 flow Applications Manual page 135

PARAMETERS MENU
Table 35: Preset frequency parameters
Index Parameter
Preset Frequency
P3.3.3.1
Mode
P3.3.3.2 Preset Frequency 0
P3.3.3.3 Preset Frequency 1
P3.3.3.4 Preset Frequency 2
P3.3.3.5 Preset Frequency 3
P3.3.3.6 Preset Frequency 4
P3.3.3.7 Preset Frequency 5
P3.3.3.8 Preset Frequency 6
P3.3.3.9 Preset Frequency 7
Preset Frequency
P3.3.3.10
Selection 0
Preset Frequency
P3.3.3.11
Selection 1
Preset Frequency
P3.3.3.12
Selection 2
* The default value of the parameter is specified by the application that you select with
parameter P1.2 Application. See the default values in Chapter 12.1 The default values of
parameters in the different applications.
Table 36: Motor potentiometer parameters
Index Parameter
Motor Potentiometer
P3.3.4.1
UP
Motor Potentiometer
P3.3.4.2
DOWN
Motor Potentiometer
P3.3.4.3
Ramp Time
Motor Potentiometer
P3.3.4.4
Reset
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
Min Max Unit
0 1
P3.3.1.1 P3.3.1.2 Hz
P3.3.1.1 P3.3.1.2 Hz
P3.3.1.1 P3.3.1.2 Hz
P3.3.1.1 P3.3.1.2 Hz
P3.3.1.1 P3.3.1.2 Hz
P3.3.1.1 P3.3.1.2 Hz
P3.3.1.1 P3.3.1.2 Hz
P3.3.1.1 P3.3.1.2 Hz
Min Max Unit
0.1 500.0 Hz/s
0 2
Default ID Description
0 = Binary coded
0 * 182
1 = Number of inputs
5.00 180
10.00 * 105
15.00 * 106
20.00 * 126
25.00 * 127
30.00 * 128
40.00 * 129
50.00 * 130
DigIN
419
SlotA.4
DigIN
420
SlotA.5
DigIN
421
Slot0.1
Default ID Description
DigIN OPEN = Not active
418
Slot0.1 CLOSED = Active
DigIN OPEN = Not active
417
Slot0.1 CLOSED = Active
10.0 331
0 = No reset
1 = Reset if stopped
1 367
2 = Reset if powered
down
