Quick Setup; Monitor - Vacon 100 flow Applications Manual

VACON · 110
Menu
I/O and hardware
User settings
Favourites *
User levels
* = The function is not available in the control panel with a text display.
3.4.1

QUICK SETUP

The Quick Setup group includes the different wizards and quick setup parameters of the
VACON 100 FLOW application. More detailed information on the parameters of this group
®
you will find in chapter 1.3 First startup and 2 Wizards.
3.4.2

MONITOR

MULTIMONITOR
With the Multimonitor function, you can collect 4 to 9 items to monitor. See 4.1.1
Multimonitor.
3
Function
User settings
Slot C
Slot D
Slot E
Real time clock
Power unit settings
Keypad
RS-485
Ethernet
Language selections
Parameter backup*
Parameter compare
Drive name
See 8.2 Favourites.
See 5 Parameters menu.
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
USER INTERFACES
