VACON · 382
Table 123: The default values of parameters in the different applications
Index Parameter
P3.5.1.2 Ctrl SIgnal 2 A
P3.5.1.4 Ctrl SIgnal 1 B
P3.5.1.7 I/O B Control
Force
P3.5.1.8 I/O B Reference
Force
P3.5.1.9 Fieldbus Control
Force
P3.5.1.10 Keypad Control
Force
P3.5.1.11 External Fault
(Close)
P3.5.1.13 Fault Reset
(Close)
P3.5.1.21 Preset Freq
Selection 0
P3.5.1.22 Preset Freq
Selection 1
12
Default
A B C D
101 101 0 0
0 0 103 101
0 0 105 102
0 0 105 102
0 0 0 0
0 0 0 0
102 102 101 0
105 105 102 0
103 103 104 0
104 104 0 0
