VACON · 212
Table 116: Fieldbus Control Word
Bit
Bit 0
Bit 1
Bit 2
Bit 3
Bit 4
Bit 5
Bit 6
Bit 7
Bit 8
Bit 9
Bit 10
Bit 11
Bit 12
Bit 13
Bit 14
Bit 15
V2.12.2 FB SPEED REFERENCE (ID 875)
This monitoring value shows the fieldbus frequency reference as a percentage of minimum
frequency to maximum frequency.
The speed reference information is scaled between the minimum and the maximum
frequency at the moment when the application received it. You can change the minimum and
the maximum frequencies after the application received the reference without an effect on
the reference.
9
Value = 0 (FALSE)
Stop request from Fieldbus
Forward direction request
No action
No action
No action
No action
(normal deceleration ramp time)
No action
No action
No action
No action
Reserved
Reserved
No action
Reserved
Reserved
Reserved
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
MONITORING VALUE DESCRIPTIONS
Descriptions
Value = 1 (TRUE)
Start request from Fieldbus
Reverse direction request
Reset active faults and alarms (on rising
edge 0=>1)
Force stop mode to Coasting
Force stop mode to Ramping
Force drive to use fast deceleration ramp
time
(1/3 of normal deceleration time)
Freeze drive frequency reference
Force Fieldbus frequency reference to zero
Force drive control place to Fieldbus con-
trol
Force drive reference source to Fieldbus
reference
Reserved
Reserved
Activate Quick Stop function
NOTE!
This will stop the drive according to set-
ting in parameter menu M3.8.5.
Reserved
Reserved
Reserved
