Vacon 100 flow Applications Manual page 265

PARAMETER DESCRIPTIONS
P3.5.1.33 EXTERNAL PID SETPOINT SELECTION (ID 1048)
Use this parameter to set the digital input signal that selects the PID setpoint value to be
used.
P3.5.1.34 RESET MAINTENANCE COUNTER 1 (ID 490)
Use this parameter to select the digital input that reset the value of the Maintenance
Counter.
P3.5.1.36 FLUSHING REFERENCE ACTIVATION (ID 530)
Use this parameter to select the digital input signal that activates the Flushing function.
The flushing frequency reference is bidirectional and a reverse command does not have an
effect on the direction of the flushing reference.
NOTE!
When you activate the digital input, the drive starts.
P3.5.1.38 FIRE MODE ACTIVATION OPEN (ID 1596)
Use this parameter to select the digital input signal that activates the Fire Mode function.
P3.5.1.39 FIRE MODE ACTIVATION CLOSE (ID 1619)
Use this parameter to select the digital input signal that activates the Fire Mode function.
P3.5.1.40 FIRE MODE REVERSE (ID 1618)
Use this parameter to select the digital input signal that gives a command for reverse
rotation direction during the Fire Mode.
This function has no effect in normal operation.
P3.5.1.41 AUTO-CLEANING ACTIVATION (ID 1715)
Use this parameter to select the digital input signal that starts the Auto-cleaning sequence.
The Auto-cleaning stops if the activation signal is removed before the process is complete.
NOTE!
If the input is activated, the drive starts.
P3.5.1.42 PUMP 1 INTERLOCK (ID 426)
Use this parameter to select the digital input signal that is used as interlock signal for the
Multi-pump system.
The selection of the application with parameter P1.2 Application gives the default value.
P3.5.1.43 PUMP 2 INTERLOCK (ID 427)
Use this parameter to select the digital input signal that is used as interlock signal for the
Multi-pump system.
