Vacon 100 flow Applications Manual page 141

PARAMETERS MENU
Table 44: Analogue input 1 settings
Index Parameter
P3.5.2.1.1 AI1 Signal Selection
AI1 Signal Filter
P3.5.2.1.2
Time
P3.5.2.1.3 AI1 Signal Range
P3.5.2.1.4 AI1 Custom. Min
P3.5.2.1.5 AI1 Custom. Max
P3.5.2.1.6 AI1 Signal Inversion
* = The selection of the application with parameter P1.2 Application gives the default value.
See the default values in 12.1 The default values of parameters in the different applications.
Table 45: Analogue input 2 settings
Index Parameter
P3.5.2.2.1 AI2 Signal Selection
AI2 Signal Filter
P3.5.2.2.2
Time
P3.5.2.2.3 AI2 Signal Range
P3.5.2.2.4 AI2 Custom. Min
P3.5.2.2.5 AI2 Custom. Max
P3.5.2.2.6 AI2 Signal Inversion
* = The selection of the application with parameter P1.2 Application gives the default value.
See the default values in 12.1 The default values of parameters in the different applications.
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
Min Max Unit
0.00 300.00 s
0 1
-160.00 160.00 %
-160.00 160.00 %
0 1
Min Max Unit
0.00 300.00 s
0 1
-160.00 160.00 %
-160.00 160.00 %
0 1
Default ID Description
AnIN
377
SlotA.1 *
0.1 * 378
0 = 0...10V / 0...20mA
0 * 379
1 = 2...10V / 4...20mA
0.00 * 380
100.00 * 381
0 = Normal
0 * 387
1 = Signal inverted
Default ID Description
AnIN See P3.5.2.1.1.
388
SlotA.2 *
See P3.5.2.1.2.
0.1 * 389
1 * 390 See P3.5.2.1.3.
0.00 * 391 See P3.5.2.1.4.
100.00 * 392 See P3.5.2.1.5.
0 * 398 See P3.5.2.1.6.
VACON · 141
