Vacon 100 flow Applications Manual page 257

PARAMETER DESCRIPTIONS
Fig. 56: The Analogue inputs menu in the text display
A. The text display
B. The name of the parameter
In the standard I/O board compilation, there are 2 analogue inputs available: the slot A
terminals 2/3 and 4/5.
Input type (graphi- Input type
cal display) (text dis-
play)
AnIN AI
AnIN AI
The location of the parameter P3.5.2.1.1 AI1 Signal Selection is the menu M3.5.2.1. The
parameter gets the default value AnIN SlotA.1 in the graphical display or AI A.1 in the text
display. The target input for the signal of the analogue frequency reference AI1 is then the
analogue input in the terminals 2/3. Use the dip switches to set the signal to be voltage or
current. See the Installation manual for more data.
Index Parameter
AI1 Signal Selec-
P3.5.2.1.1
To change the input from AI1 to, for example, the analogue input on your option board in slot
C, obey these instructions.
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
A
Slot Input #
A 1
A 2
Default
AnIN SlotA.1
tion
B
C
C. The value of the parameter, that is, the
set analogue input
Explanation
Analogue input #1 (terminals 2/3) on a board in
Slot A (standard I/O board).
Analogue input #2 (terminals 4/5) on a board in
Slot A (standard I/O board).
ID Description
377
VACON · 257
10
