Vacon 100 flow Applications Manual page 384

VACON · 384
Table 123: The default values of parameters in the different applications
Index Parameter
P3.5.2.2.6 AI2 Signal Inver-
sion
P3.5.3.2.1 RO1 Function
P3.5.3.2.4 RO2 Function
P3.5.3.2.7 RO3 Function
P3.5.4.1.1 AO1 Function
P3.5.4.1.2 AO1 Filter Time
P3.5.4.1.3 AO1 Min Signal
P3.5.4.1.4 AO1 Min Scale
P3.5.4.1.5 AO1 Max Scale
P3.10.1 Automatic Reset 0
P3.13.2.5 PID Setpoint
Selection
P3.13.2.6 PID Setpoint
Source 1
P3.13.2.10 PID Setpoint
Source 2
P3.13.3.1 PID Feedback
Function
P3.13.3.3 PID Feedback
Source
P3.15.1 Multi-Pump
Mode
P3.15.2 Number of
Pumps
12
Default
A B C D
0 0 0 0
2 2 2 49
3 3 3 50
1 1 1 51
2 2 2 2
1.0 1.0 1.0 1.0
0 0 0 0
0.0 0.0 0.0 0.0
0.0 0.0 0.0 0.0
0 1 1
0 0 0 0
- - 1 1
- - - -
- - 1 1
- - 2 2
- - - 0
1 1 1 3
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
Unit ID Description
E
0 398
2 11001 2 = Run
3 11004 3 = Fault
1 11007 1 = Ready
2 10050 2 = Output Fre-
quency
1.0 s 10051
0 10052
0.0 10053
0.0 10054
1 731 0 = Disabled
1 = Enabled
102 1047 0 = DigIN Slot0.1
102 = DigIN SlotA.
3
1 332 1 = Keypad Set-
point 1
2 431 2 = Keypad Set-
point 2
1 333 1 = Only Source1
in use
2 334 2 = AI2
2 1785 0= Single drive
1= Multifollower
2= Multimaster
3 1001
APPENDIX 1
