USER INTERFACES
NOTE!
The Multimonitor menu is not available in the text display.
TREND CURVE
The Trend curve function is a graphical presentation of 2 monitor values at the same time.
See 4.1.2 Trend curve.
BASIC
The basic monitoring values can include statuses, measurements, and the actual values of
parameters and signals. See 4.1.3 Basic.
I/O
You can monitor the statuses and levels of the values of input and output signals. See 4.1.4
I/O.
TEMPERATURE INPUTS
See 4.1.5 Temperature inputs.
EXTRAS/ADVANCED
You can monitor different advanced values, for example fieldbus values. See 4.1.6 Extras and
advanced.
TIMER FUNCTIONS
You can monitor the timer functions and the Real Time Clock. See 4.1.7 Timer functions
monitoring.
PID CONTROLLER
You can monitor the PID controller values. See 4.1.8 PID controller monitoring.
EXTERNAL PID CONTROLLER
You can monitor the values that are related to the external PID controller. See 4.1.9 External
PID controller monitoring.
MULTI-PUMP
You can monitor the values that are related to the operation of more than 1 drive. See 4.1.10
Multi-pump monitoring.
MAINTENANCE COUNTERS
You can monitor the values related to the maintenance counters. See 4.1.11 Maintenance
counters.
FIELDBUS DATA
You can see the fieldbus data as monitor values. Use this function, for example, during the
