Table 50: Digital output settings on standard I/O board, Slot B
Index Parameter
P3.5.3.2.1 RO1 Function
P3.5.3.2.2 RO1 ON Delay
P3.5.3.2.3 RO1 OFF Delay
P3.5.3.2.4 RO2 Function
P3.5.3.2.5 RO2 ON Delay
P3.5.3.2.6 RO2 OFF Delay
P3.5.3.2.7 RO3 Function
* = The selection of the application with parameter P1.2 Application gives the default value.
See the default values in 12.1 The default values of parameters in the different applications.
THE DIGITAL OUTPUTS OF THE EXPANDER SLOTS C, D AND E
Shows only the parameters for the outputs on option boards in slots C, D and E. Make the
selections as in RO1 Function (P3.5.3.2.1).
This group or these parameters do not show, if there are no digital outputs in slots C, D or E.
5
Min Max Unit
0 74
0.00 320.00
0.00 320.00
0 56
0.00 320.00
0.00 320.00
0 56
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
Default ID
55 = Multi-pump K7
control
56 = Multi-pump K8
control
69 = Selected parame-
Varies 11001 ter set
72 = AHF Cap Discon-
nect
73 = AHF Cap Discon-
nect Inv
74 = Run indication
s 0.00 11002
s 0.00 11003
Varies 11004 See P3.5.3.2.1.
s 0.00 11005 See M3.5.3.2.2.
s 0.00 11006 See M3.5.3.2.3.
See P3.5.3.2.1. Shows
Varies 11007 if more than 2 output
relays are installed.
PARAMETERS MENU
Description
