WIZARDS

2 WIZARDS
2.1

STANDARD APPLICATION WIZARD

The application wizard helps you to set the basic parameters that are related to the
application.
To start the Standard application wizard, set the value Standard to parameter P1.2
Application (ID 212) in the keypad.
NOTE!
If you start the Standard application wizard from the Startup wizard, the wizard
goes directly to step 11.
Set a value for P3.1.2.2 Motor Type (so that it agrees
with the nameplate of the motor)
1
Set a value for P3.1.1.1 Motor Nominal Voltage (so
2
that it agrees with the nameplate of the motor)
Set a value for P3.1.1.2 Motor Nominal Frequency
3
(so that it agrees with the nameplate of the motor)
Set a value for P3.1.1.3 Motor Nominal Speed (so
4
that it agrees with the nameplate of the motor)
Set a value for P3.1.1.4 Motor Nominal Current (so
5
that it agrees with the nameplate of the motor)
Step 6 shows only, if you selected Induction Motor in step 1.
6 Set a value for P3.1.1.5 Motor Cos Phi
Set a value for P3.3.1.1 Minimum Frequency Refer-
7
ence
Set value for P3.3.1.2 Maximum Frequency Refer-
8
ence
9 Set a value for P3.4.1.2 Acceleration Time 1
10 Set value for P3.4.1.3 Deceleration Time 1
Select the control place that gives the drive the
start or stop commands and the frequency refer-
11
ence.
The Standard application wizard is completed.
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
PM motor
Induction motor
Reluctance motor
Range: Varies
Range: 8.00-320.00 Hz
Range: 24-19200 rpm
Range: Varies
Range: 0.30-1.00
Range: 0.00-P3.3.1.2 Hz
Range: P3.3.1.1-320.00 Hz
Range: 0.1-3000.0 s
Range: 0.1-3000.0 s
I/O Terminal
Fieldbus
Keypad
