Vacon 100 flow Applications Manual page 378

VACON · 378
Fault
Fault ID
code
101 1101
105 1105
109 1109
1409
111 1315
1316
112 1317
1318
113 1113
1313
11
Fault name
Feedback supervision The PID controller: the feed-
fault (PID1) back value is not in the
supervision limits (P3.13.6.2
and P3.13.6.3) and the delay
(P3.13.6.4), if you set the
delay.
Feedback supervision The external PID controller:
fault (ExtPID) the feedback value is not in
the supervision limits
(P3.14.4.2 and P3.14.4.3)
and the delay (P3.14.4.4), if
you set the delay.
Input pressure super- The supervision signal of the
vision input pressure (P3.13.9.2) is
lower than the alarm limit
(P3.13.9.7).
The supervision signal of the
input pressure (P3.13.9.2) is
lower than the fault limit
(P3.13.9.8).
Temperature fault 1 1 or more of the tempera-
ture input signals (set in
P3.9.6.1) is higher than the
alarm limit (P3.9.6.2).
1 or more of the tempera-
ture input signals (set in
P3.9.6.1) is higher than the
fault limit (P3.9.6.3).
Temperature fault 2 1 or more of the tempera-
ture input signals (set in
P3.9.6.5) is higher than the
fault limit (P3.9.6.6).
1 or more of the tempera-
ture input signals (set in
P3.9.6.5) is higher than the
fault limit (P3.9.6.7).
Pump running time In the Multi-pump system, 1
or more of the pump run-
time counters is above a
user-specified alarm limit.
In the Multi-pump system, 1
or more of the pump run-
time counters is above a
user-specified alarm limit
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
Possible cause
Do a check of the process.
Do a check of the parameter set-
tings, the supervision limits and
the delay.
Do a check of the process.
Do a check of the parameters in
menu M3.13.9.
Do a check of the input pressure
sensor and connections.
Find the cause of the temperature
rise.
Do a check of the temperature
sensor and connections.
If no sensor is connected, make
sure that the temperature input is
hardwired.
See the option board manual for
more information.
Do the necessary maintenance
actions, reset the runtime counter
and reset the alarm. See Pump
running time counters.
FAULT TRACING
How to correct the fault
