MONITORING VALUE DESCRIPTIONS
NOTE!
The values are visible as checkboxes on the graphical display. If a box is selected,
the value is active.
V2.6.5 DIN STATUS WORD 1 (ID 56)
This monitoring value shows the bit-coded status of the digital input signals.
The monitoring value is a 16 bit word, where each bit shows the status of 1 digital input.
From each slot, 6 digital inputs are read. Word 1 starts from the input 1 in slot A (bit0) and
ends with input 4 in slot C (bit15).
V2.6.6 DIN STATUS WORD 2 (ID 57)
This monitoring value shows the bit-coded status of the digital input signals.
The monitoring value is a 16 bit word, where each bit shows the status of 1 digital input.
From each slot, 6 digital inputs are read. Word 2 starts from the input 5 in slot C (bit0) and
ends with input 6 in slot E (bit13).
V2.6.7 MOTOR CURRENT 1 DECI (ID 45)
This monitoring value shows the measured current of the motor with the fixed number of
decimals and that is less filtered.
This monitoring value can be used for example with fieldbus to get the correct value so that
the enclosure size does not have an effect, or for monitoring when less filtering time is
needed for the motor current.
V2.6.8 FREQUENCY REFERENCE SOURCE (ID 1495)
This monitoring value shows the momentary frequency reference source.
V2.6.9 LAST ACTIVE FAULT CODE (ID 37)
This monitoring value shows the fault code of latest activated fault that is not reset.
V2.6.10 LAST ACTIVE FAULT ID (ID 95)
This monitoring value shows the fault ID of latest activated fault that is not reset.
V2.6.11 LAST ACTIVE ALARM CODE (ID 74)
This monitoring value shows the alarm code of latest activated alarm that is not reset.
V2.6.12 LAST ACTIVE ALARM ID (ID 94)
This monitoring value shows the alarm ID of latest activated alarm that is not reset.
V2.6.13 MOTOR REGULATOR STATUS (ID 77)
This monitoring value shows the bit-coded status of the motor limit controllers.
