Vacon 100 flow Applications Manual page 94

VACON · 94
3 If the value is numerical, move from digit to digit
with the arrow buttons Left and Right. Change the
digits with the arrow buttons Up and Down.
4 To accept the change, push the OK button. To
ignore the change, go back to the level where you
were before with the Back/Reset button.
THE SELECTION OF MORE THAN 1 VALUE
Some parameters let you to make a selection of more than 1 value. Select a checkbox at
each necessary value.
1 Find the parameter. There is a symbol on the
display when a checkbox selection is possible.
3
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
USER INTERFACES
STOP READY
MinFreqReference
ID:101 P3.3.1.1
Min: 0.00Hz
Max: 50.00Hz
READY
STOP
MinFreqReference
ID:101 P3.3.1.1
Min: 0.00Hz
Max: 50.00Hz
READY
STOP
Interval 1
ID:1466 P3.12.1.3
ON Time
00:00:00
OFF Time
00:00:00
Days
A
A. The symbol of the checkbox
selection
I/O
00.00 Hz
I/O
11.00 Hz
I/O
0
