WIZARDS
11 Set a value for P3.4.1.2 Acceleration Time 1
12 Set a value for P3.4.1.3 Deceleration Time 1
Next the wizard goes to steps that are specified by the application.
Select the control place (where you give the start
and stop commands and the frequency reference)
13
The HVAC application wizard is completed.
Table 14: Preset values of parameters
Index Parameter
P3.1.4.1 U/f Ratio
P3.2.4 Start Function
P3.2.5 Stop Function
P3.4.1.2 Acceleration Time
P3.4.1.3 Deceleration Time
2.3

PID CONTROL APPLICATION WIZARD

The application wizard helps you to set the basic parameters that are related to the
application.
To start the PID control application wizard, set the value PID control to parameter P1.2
Application (ID 212) in the keypad.
NOTE!
If you start the application wizard from the Startup wizard, the wizard goes directly
to step 11.
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
Range: 0.1-3000.0 s
Range: 0.1-3000.0 s
I/O Terminal
Fieldbus
Keypad
Pump
Linear Squared
Ramping Flying start
Ramping Coasting
5.0 s 30.0 s
5.0 s 30.0 s
VACON · 79
Process type
Fan Compressor
Linear
Ramping
Ramping
3.0 s
3.0 s
