PARAMETER DESCRIPTIONS
10.9

SUPERVISIONS

P3.8.1 SUPERVISION #1 ITEM SELECTION (ID 1431)
Use this parameter to select the supervision item.
The output of the supervision function can be selected to the relay output.
P3.8.2 SUPERVISION #1 MODE (ID 1432)
Use this parameter to set the supervision mode.
When the 'Low limit' mode is selected, the output of the supervision function is active when
the signal is below the supervision limit.
When the'High limit' mode is selected, the output of the supervision function is active when
the signal is above the supervision limit.
P3.8.3 SUPERVISION #1 LIMIT (ID 1433)
Use this parameter to set the supervision limit for the selected item.
The unit shows automatically.
P3.8.4 SUPERVISION #1 LIMIT HYSTERESIS (ID 1434)
Use this parameter to set the supervision limit hysteresis for the selected item.
The unit shows automatically.
P3.8.5 SUPERVISION #2 ITEM SELECTION (ID 1435)
Use this parameter to select the supervision item.
The output of the supervision function can be selected to the relay output.
P3.8.6 SUPERVISION #2 MODE (ID 1436)
Use this parameter to set the supervision mode.
P3.8.7 SUPERVISION #2 LIMIT (ID 1437)
Use this parameter to set the supervision limit for the selected item.
The unit shows automatically.
P3.8.8 SUPERVISION #2 LIMIT HYSTERESIS (ID 1438)
Use this parameter to set the supervision limit hysteresis for the selected item.
The unit shows automatically.
10.10

PROTECTIONS

10.10.1

GENERAL

P3.9.1.2 RESPONSE TO EXTERNAL FAULT (ID 701)
Use this parameter to select the response of the drive to an 'External Fault'.
