Oil Pressure Relief Valve - SSANGYONG 1999 Musso Service Manual

OIL PRESSURE RELIEF VALVE

Preceding Work : Removal of oil pan
1 Screw Plug ................................................ 50 Nm
2 Compression Spring
Removal & Installation Procedure
1. Remove the screw plug (1).
Installation Notice
Tightening Torque
2. Remove the spring (2), guide pin (3) and the piston (4).
3. Installation should follow the removal procedure in the
reverse order.
Notice
Don't use the seal for the screw plug.
M162 ENGINE MECHANICAL 1B1-101
3 Guide Pin
4 Piston
50 Nm
