AT&T MERLIN LEGEND Release 3.0 System Programming Manual page 598

Remote Access Features
Console Display/Instructions
3 Erase the current code ( nnnn ).
BarrierCode xx:
Enter yy digits (O-9, *)
code
nnnn
Backspace Next
Exit Enter
4 Enter a code of up to 11 digits [ N = any combination of 0 to 9 and an asterisk (*)].
Continue to assign the code to another barrier code ID number or go to
5
Step 6.
Select Next.
6 Save your entry.
Select Enter.
Return to the System Programming menu.
7
Select Exit three times.
Remote Access with Barrier Codes
Use this procedure to change the class of restriction for individual remote
access barrier codes. The class of restriction assigned to each barrier code
allows or denies the use of the following system features:
Restriction.
and/or toll calls, and includes the following settings:
Unrestricted
Toll restricted
Outward restricted
ARS Facility Restriction
of outgoing trunks by assigning a facility restriction level (FRL) from 0
through 6. The FRL ranges from 0 (most restrictive) to 6 (least restrictive).
The FRL value assigned here is the opposite of the FRL value assigned
to the ARS route, where a value of 0 is the least restrictive, and a value of
6 is the most restrictive.
Allowed Lists Assignment.
remote access users are restricted from making local or toll calls.
Disallowed Lists Assignment.
when remote access users are not restricted from making local or toll calls.
4-248
Programming Procedures
Additional Information
xx = barrier code ID number entered in
Step 1
yy = barrier code length
Press Drop.
Dial or type [ N ].
Return to Step 3. The next barrier code number
will be displayed on Line 1.
Determines whether remote access users can make local
Level (Hybrid/PBX only). Allows or restricts use
Assigns Allowed Lists and is used when
Assigns Disallowed Lists and is used
PC
[ Alt ] + [ P ]
←
[ F9 ]
[ F10 ]
[ F5 ] [ F5 ] [ F5 ]
