System Programming Console
I
OutTrunk Dial:
Enter Trunks w/TouchTone
Lines 01-20
—
Lines 21-40
—
— Lines 41-60
—
Lines 61-80
Exit
Figure l-4. Selecting a Block of Lines/Trunks
Console and DSS Lights
The red and green lights (LEDs) next to eachof the 20 Iine buttons show the
status of the line/trunk options. LEDs on the DSS show the status of features
programmed on extensions. See Appendix C, "LED Displays," for more
information.
Console Lights
The green and red LEDs next to each button on the console will display the
status of the line/trunk option that is being programmed. For example when you
select Pools from the Lines Trunks menu, the red LED will be off if the selected
line is not in a pool and on if the line is in a pool. Appendix C "LED Displays, "
provides a table that shows the default LED status for line/trunk options.
DSS Lights
The lights on the DSS (if one is attached to the console) show the status of
features being programmed on the extensions. When you select a feature from
a menu, the red LED next to the DSS button is on, off, or flashing, depending on
whether the feature is programmed on the corresponding extension. For
example, when you select Toll Restrict from the Restrictions menu, the red
LED next to the DSS button lights for each toll-restricted extension. Appendix C
"LED Displays, " provides a table that shows the default DSS status of LEDs for
system features.
For a single line, go to
Entry Mode
—
For a block of lines, go to
Single Line Procedure.
Block Procedure.
