CDM-600 Satellite Modem
Installation
*
#10 Socket head
*
BRACKET
BOLTS
* Note: Components of mounting kit KT/6228-1
Figure 2-1. Installation of the Optional Mounting Bracket, KT/6228-2
MN/CDM600.IOM
screw
*
Support
Bracket
Bracket
#10 Flat Washer
#10 Hex Nut
Equipment
Rack
Mounting
Rail
Back of Modem
2–3
Revision 7
MN/CDM600.IOM
