Configuring a Priority
for RIP
Configuring RIP Route
Redistribution
Optimizing the RIP
Network
To do...
Define a filtering policy
for outgoing routes
n
Using the filter-policy import command filters incoming routes. Routes not
■
passing the filtering will be neither installed into the routing table nor
advertised to neighbors.
Using the filter-policy export command filters outgoing routes, including
■
routes redistributed with the import-route command.
Multiple IGP protocols may run in a router. If you want RIP routes to have a higher
priority than those learned from other routing protocols, you should assign RIP a
smaller priority value to influence optimal route selection.
Follow these steps to configure a priority for RIP:
To do...
Enter system view
Enter RIP view
Configure a priority for RIP
Follow these steps to configure RIP route redistribution:
To do...
Enter system view
Enter RIP view
Configure a default metric for
redistributed routes
Redistribute routes from other
protocols or processes
This section covers the following topics:
"Configuring RIP Timers" on page 982
■
"Configuring the Split Horizon and Poison Reverse" on page 982
■
"Configuring the Maximum Number of Load Balanced Routes" on page 983
■
"Enabling CheckZero Field Check on RIPv1 Messages" on page 983
■
"Enabling Source IP Address Check on Incoming RIP Updates" on page 984
■
Use the command...
filter-policy { acl-number | ip-prefix
ip-prefix-name } export [ protocol
[ process-id ] | interface-type
interface-number ]
Use the command...
system-view
rip [ process-id ] [ vpn-instance
vpn-instance-name ]
preference [ route-policy
route-policy-name ] value
Use the command...
system-view
rip [ process-id ]
[ vpn-instance
vpn-instance-name ]
default-cost value
import-route protocol
[ process-id ] [ allow-ibgp ]
[ cost cost | route-policy
route-policy-name | tag tag ]
*

Optimizing the RIP Network

Remarks
Required
No outbound filtering is
configured by default.
Remarks
--
--
Optional
100 by default
Remarks
--
--
Optional
The default metric of a
redistributed route is 0 by
default.
Required
By default, RIP does not
redistribute any other
protocol route.
981
