Network diagram
Figure 302 Network diagram for static route configuration
Eth1/1
1.1.4.1/30
Eth1/0
1.1.2.3/24
Host A Router A
1.1.2.2/24
Configuration procedure
1 Configuring IP addresses for interfaces (omitted)
2 Configuring static routes

# Enter system view

<RouterA> system-view
# Configure a default route on Router A.
[RouterA] ip route-static 0.0.0.0 0.0.0.0 1.1.4.2
# Configure two static routes on Router B.
<RouterB> system-view
[RouterB] ip route-static 1.1.2.0 255.255.255.0 1.1.4.1
[RouterB] ip route-static 1.1.3.0 255.255.255.0 1.1.5.6
# Configure a default route on Router C.
<RouterC> system-view
[RouterC] ip route-static 0.0.0.0 0.0.0.0 1.1.5.5
3 Configure the hosts
The default gateways for the three hosts Host A, Host B and Host C are 1.1.2.3,
1.1.6.1 and 1.1.3.1 respectively. The detailed configuration procedure is omitted.
4 Display the configuration result
# Display the IP routing table of Router A.
[RouterA] display ip routing-table
Routing Tables: Public
Destinations : 8
Destination/Mask
0.0.0.0/0
Host B
1.1.6.2/24
Eth1/2
1.1.6 .1/24
Eth1 /0
Eth1/1
1.1.4 .2/30
1.1.5 .5/30
Router B
Routes : 8
Proto Pre Cost
Static 60 0
Configuration Example
Eth1 /1
1 .1.5.6/30
Eth1/0
1.1.3 .1/24
Router C
Host C
1.1.3.2/24
NextHop Interface
1.1.4.2 Serial2/0
