1038 C 62: IP 6 BGP C
HAPTER V ONFIGURATION
Connect the two IPv6 networks through the IPv4/MPLS network with the 6PE
■
feature.
Network diagram
Figure 306 Network diagram for 6PE configuration
S2/0
Loop 0
1::1/128
S2 /0
CE 1
IPv6 network
Customer site
Configuration procedure
1 Configure CE 1
# Enable IPv6 packet forwarding.
<CE1> system-view
[CE1] ipv6
# Specify IP addresses for interfaces.
[CE1] interface serial 2/0
[CE1-Serial2/0] ipv6 address auto link-local
[CE1-Serial2/0] quit
[CE1] interface loopback0
[CE1-LoopBack0] ipv6 address 1::1/128
[CE1-LoopBack0] quit
# Configure an IPv6 static route to PE 1.
[CE1] ipv6 route-static :: 0 serial2/0
2 Configure PE 1
# Enable IPv6 packet forwarding, MPLS and LDP.
<PE1> system-view
[PE1] ipv6
[PE1] mpls lsr-id 2.2.2.2
[PE1] mpls
[PE1-mpls] lsp-trigger all
[PE1-mpls] quit
[PE1] mpls ldp
[PE1-mpls-ldp] quit
Loop 0
2.2.2.2/32
2::2 /128
S 2/1
1 .1.1.2/16
1 .1.1.1/16
IBGP
PE 1
IPv4/MPLS network
Loop 0
3.3.3.3/32
3::3/128
S2/1
S 2/0
PE 2
Loop 0
4::4 /128
S2 /0
CE 2
IPv6 network
Customer site
