Goodrive35 inverters
Note:
1. The inverters of 380 V (≥37 kW) supports external DC reactors and external brake units, but it is
necessary to remove the copper tag between P1 and (+) before connecting. DC reactors and external
brake units are optional.
2. The inverters of 380 V (≤30 kW) supports external brake resistors which are optional.
3. The inverters of 660 V supports external DC reactors and external brake units, but it is necessary
to remove the copper tag between P1 and (+) before connecting. DC reactors and external brake
units are optional.

3.3 Product specification

Function
Input voltage (V)
Power input
Input current (A)
Input frequency ( Hz)
Output voltage (V)
Output current (A)
Power output
Output power ( kW)
Output frequency ( Hz) 0 – 400 Hz
Adjustable-speed ratio
Speed control accuracy ±0.2% (SVC) ± 0.02% (VC)
Technical Speed fluctuation
control
Torque response
feature
Torque control accuracy 10% (SVC)
Overload capability
Running
Frequency setting
control
feature
Control mode
Motor type
Starting torque
method
AC 3PH 380 V (-15%) – 440 V (+10%)
Rated voltage: 380 V
AC 3PH 520 V (-15%) – 690 V (+10%)
Rated voltage: 660 V
Refer to the rated value
50 Hz or 60 Hz
Allowed range: 47 – 63 Hz
0 – input voltage
Refer to the rated value
Refer to the rated value
SVPWM, SVC and VC
Asynchronous motor and permanent magnet
synchronous motor
Asynchronous motor 1: 200 (SVC) synchronous motor 1:
20 (SVC) 1: 1000 (VC)
± 0.3% (SVC)
<20 ms (SVC) <10 ms (VC)
5% (VC)
Asynchronous motor: 0.25 Hz/150% (SVC)
Synchronous motor: 2.5 Hz/150% (SVC) 0 Hz/150%
(VC)
150% of rated current: 1 minute
180% of rated current: 10 seconds
200% of rated current: 1 second
Digital setting, analog setting, pulse frequency setting,
multi-step speed running setting, simple PLC setting, PID
setting, MODBUS communication setting, PROFIBUS
