Goodrive100-PV Series Solar Pump Inverter
2.1 Unpacking inspection
Check as follows after receiving products:
1.
Check that there are no damage and humidification to the package. If not, please
contact with local agents or INVT offices.
2.
Check the information on the type designation label on the outside of the package to
verify that the drive is of the correct type. If not, please contact with local dealers or
INVT offices.
3.
Check that there are no signs of water in the package and no signs of damage or
breach to the inverter. If not, please contact with local dealers or INVT offices.
4.
Check the information on the type designation label on the outside of the package to
verify that the name plate is of the correct type. If not, please contact with local
dealers or INVT offices.
Check to ensure the accessories (including user's manual and control keypad) inside
5.
the device is complete. If not, please contact with local dealers or INVT offices.
2.2 Product nameplate
Note: This is a nameplate example of a standard inverter product. The CE/TUV/IP20 marking
on the top right will be marked according to actual certification conditions.
2.3 Model designation code
A model designation code contains product information. You can find the model designation
code on the inverter nameplate and simplified nameplate.
2 Product overview
Model: GD100-2R2G-S2-PV
Power(Output): 2.2kW
Input: DC 150V-440V
AC 1PH 220V (-15%)-240V (+10%) 24A 47 Hz-63Hz
Output: AC 3PH 0V-Uinput 10A 0Hz-400Hz
S/N:
Shenzhen INVT Electric Co., Ltd.
GD100 – 5R5G – 4 5 – PV
①
Made in china
②
③
④
-5-
Product overview
I P20
⑤
