SSANGYONG 1999 Musso Service Manual page 1208

Specifications . . . . . . . . . . . . . . . . . . . . . . . 5D2-1
General Specifications . . . . . . . . . . . . . . . . . 5D2-1
Schematic and Routing Diagrams . . . . . . . 5D2-2
TOD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5D2-2
T.C.C.U . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5D2-3
Function Description . . . . . . . . . . . . . . . . . 5D2-4
TOD Control Unit . . . . . . . . . . . . . . . . . . . 5D2-12
Control Unit Diagram . . . . . . . . . . . . . . . . 5D2-14
TOD Control Unit . . . . . . . . . . . . . . . . . . . . 5D2-14
Diagnosis . . . . . . . . . . . . . . . . . . . . . . . . . 5D2-15
Diagnostic Tests . . . . . . . . . . . . . . . . . . . . . 5D2-15
Diagnostic Trouble Codes (DTC's) . . . . . . . 5D2-17
Application
Model
Length (mm)
Weight (kg)
Shift Mode
Gear Ratio
Oil
Max. Torque
SECTION 5D2
TRANSFER CASE (TOD)
TABLE OF CONTENTS
SPECIFICATIONS
GENERAL SPECIFICATIONS
High
Low
Specification
Capacity
Interval
Coding . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5D2-18
Eliminate the Memorized Fault Code . . . . . 5D2-20
Diagnosis . . . . . . . . . . . . . . . . . . . . . . . . . . 5D2-21
Maintenance and Repair . . . . . . . . . . . . . 5D2-33
On-Vehicle Service . . . . . . . . . . . . . . . . . . . 5D2-33
TOD Control Unit . . . . . . . . . . . . . . . . . . . . 5D2-33
Transfer Case (TOD) . . . . . . . . . . . . . . . . . 5D2-34
Speed Sensor in Front and Rear
Propeller Shaft . . . . . . . . . . . . . . . . . . . . . 5D2-38
Replacement of Oil . . . . . . . . . . . . . . . . . . . 5D2-40
Unit Repair . . . . . . . . . . . . . . . . . . . . . . . . 5D2-41
Transfer Case . . . . . . . . . . . . . . . . . . . . . . . 5D2-41
Description
TOD(Torque On Demand) Transfer Case (4423E)
4H and 4L
2.48 : 1
ATF S-3, S-4 or Dexron II, III
.
=
Inspect Every 15,000km, Replace Every 50,000km
550 lb
·
343.0
36.6
1 : 1
1.4 L
.
.
ft ( 76kg m)
=
.
·
