5D2-6 TRANSFER CASE (TOD)
Input/Output diagram
TOD control unit and main wiring harness is linked by 30 pin
connector. Each pin joins with switche and actuator whose
details refer to the below diagram.
Battery Power
Ignition ON/OFF
Position Encoder 1
Position Encoder 2
Position Encoder 3
Position Encoder 4
4H / 4L Switch Signal
A/T "N" Position Signal
Speed / TPS Supply
Front Speed Sensor Input
Rear Speed Sensor Input
ABS Operation Signal
Brake Switch Signal
4
22
19
5
23
27
2
10
15
1
28
14
30
3
9
21
24
6
16
7
11
29
13
25
20
26
17
18
CAN H
CAN L
Shift Motor output port
(LO-HI)
Shift Motor output port
(HI-LO)
EMC
'4L' Indicator
Position Return
'4WD CHECK' IND
TPS/speed Sensor Ground
(Speed / TPS Return)
K-Line
