SW-CTL (Switch Control)
System Technician-Demanded Tests: Descriptions
and Error Codes
Always investigate tests in the order presented in the table below when inspecting
errors in the system. By clearing error codes associated with the Switch Control
Reset Test, for example, you may also clear errors generated from other tests in
the testing sequence.
Order of Investigation
Switch Control Reset Test (#93)
Control Channel Interface Test (#92)
Control Channel Transmission Test (#94)
Time of Day Clock Test (#95)
Control Channel Loop Around Test (DATA-BD) (#52) (a)
NPE Audit Test (DATA-BD) (#50) (a)
Data Channel Reset Test (DATA-CHL) (#107) (b)
Data Channel Interface Test (DATA-CHL) (#108) (b)
Maintenance Loop Around Test (DATA-CHL) (#109) (b)
Data Channel Crosstalk Test (DATA-CHL) (#110) (b)
Data Channel Local Loop Back Test (DATA-CHL) (#111) (b)
1. D = Destructive; ND = Nondestructive
Notes:
a. Refer to DATA-BD (Network Control Circuit Pack) Maintenance
documentation for a description of these tests.
b. Refer to DATA-CHL (Network Control Channel) Maintenance
documentation for a description of these tests.
555-233-119
Short Test Long Test
Sequence Sequence
X
X X
X X
X X
X X
X
X
X
X X
X X
X X
Continued on next page
Issue 5 October 2002
1
D/ND
D
ND
ND
ND
ND
ND
D
D
ND
ND
ND
