CONTROL COMMAND

Remote jack (CI-V) information (Continued)

D Command table

Cmd. Sub cmd. Data
00 see p. 20-11 Send the operating frequency for
01 see p. 20-11 Send the operating mode for
02 see p. 20-12 Read the band edge frequencies
03 see p. 20-11 Read the operating frequency
04 see p. 20-11 Read the operating mode
05 see p. 20-11 Send the operating frequency
06 00
01
02
03
04
05
06
07
08
17
07
00
01
A0
B0
08
0001 to
0109
A0 01
02
03
04
05
09
0A
0B
0C
0D
0E 00
01
02
03
12
13
22
23
24
A1
A2
A3
A4
A5
A6
A7
B0
B1
D0
D3
Description
transceive
transceive
Select the LSB mode
Select the USB mode
Select the AM mode
Select the CW mode
Select the RTTY mode
Select the FM mode
Select the WFM mode
Select the CW-R mode
Select the RTTY-R mode
Select the DV mode
Select the VFO mode
Select VFO A
Select VFO B
Equalize VFO A and VFO B
Exchange VFO A and VFO B
Select the Memory mode
Select the Memory channel
(0001=M-CH01 to 0099=M-CH99,
0100=1A, 0101=1B, 0102=2A,
0103=2B, 0104=3A, 0105=3B,
0106=144-C1, 0107=144-C2,
0108=430-C1, 0109=430-C2)
Select Memory Bank A
Select Memory Bank B
Select Memory Bank C
Select Memory Bank D
Select Memory Bank E
Memory write
Memory copy to VFO
Memory clear
Read offset frequency
Send offset frequency
Scan stop
Programmed/memory scan start
Programmed scan start
∂F scan start
Fine programmed scan start
Fine ∂F scan start
Memory scan start
Select memory scan start
Mode select scan start
Set the ±5 kHz ∂F scan span
Set the ±10 kHz ∂F scan span
Set the ±20 kHz ∂F scan span
Set the ±50 kHz ∂F scan span
Set the ±100 kHz ∂F scan span
Set the ±500 kHz ∂F scan span
Set the ±1 MHz ∂F scan span
Set as the Non-select Memory channel
Set as the Select Memory channel
Set Scan resume function OFF
Set Scan resume function ON
Cmd. Sub cmd. Data
0F 00
01
11
12
00
01
10
11
12
10 00
01
02
03
04
05
06
07
08
09
10
11
12
11 00
12
13 00
01
02
14 01 0000 to
0255
02 0000 to
0255
03 0000 to
0255
06 0000 to
0255
07 0000 to
0255
08 0000 to
0255
09 0000 to
0255
0A 0000 to
0255
0B 0000 to
0255
0C 0000 to
0255
0D 0000 to
0255
20-3
Description
Read Split function OFF
Read Split function ON
Read DUP– operation
Read DUP+ operation
Set Split function OFF
Set Split function ON
Set the simplex operation
Set DUP– operation
Set DUP+ operation
Send/read the 10 Hz (1 Hz) tuning
step
Send/read the 0.1 kHz tuning step
Send/read the 1 kHz tuning step
Send/read the 5 kHz tuning step
Send/read the 6.25 kHz tuning step
Send/read the 9 kHz tuning step
Send/read the 10 kHz tuning step
Send/read the 12.5 kHz tuning step
Send/read the 20 kHz tuning step
Send/read the 25 kHz tuning step
Send/read the 50 kHz tuning step
Send/read the 100 kHz tuning step
Send/read the 1 MHz tuning step
Send/read Attenuator OFF
Send/read 12 dB attenuator
Announce the operating frequency,
operating mode and S-meter level
by voice synthesizer
Announce the operating frequency
and S meter level by voice synthe-
sizer
Announce the operating mode by
voice synthesizer
Send/read the AF level
(0000=min. to 0255=max.)
Send/read the RF gain level
(0000=min., 0255=max.)
Send/read the squelch level
(0000=min. to 0255=max.)
Send/read the NR level
(0000=0% to 0255=100%)
Send/read the inner [TWIN PBT]
position
(0000=Cutting the higher passband
edge, 0128=center, 0255=Cutting
the lower passband edge)
Send/read the outer [TWIN PBT]
position
(0000=Cutting the higher passband
edge, 0128=center, 0255=Cutting
the lower passband edge)
Send/read the CW PITCH
(0000=300 Hz, 0128=600 Hz,
0255=900 Hz)
Send/read the RF power level
(0000=min. to 0255=max.)
Send/read the MIC gain level
(0000=min. to 0255=max.)
Send/read the KEY SPEED
(0000=6 WPM to 0255=48 WPM)
Send/read the NOTCH setting
(0000=lowest, 0128=center,
0255=highest)
