17
SET MODE
QSO/RX Log Set mode (Continued)
The QSO log contents are shown below:
Content Example
TX/RX TX
Date 12/23/2012
13:51:48
Frequency 438.010000 438.010000 Operating frequencies
Mode DV
My Latitude 34.764667
My Longitude 135.375333 135.375333 Your longitude (unit: degree) +: East longitude, –: West longitude
My Altitude 50.5
RF Power 100%
S Meter (Blank)
RPT Call Sign JP3YHJ A
TX Call Sign CQCQCQ
RX Call Sign (Blank)
RX Latitude (Blank)
RX Longitude (Blank)
RX Altitude (Blank)
The RX History log contents are shown below:
Content
Frequency 438.010000
Mode DV
Caller JA3YUA A
/ 7100
Called CQCQCQ
Rx RPT1 JP3YHH G
Rx RPT2 JP3YHJ A
Message Hello CQ D-STAR!
Status (Blank)
Received date 12/23/2012
13:51:48
BK *
EMR *
Latitude 34.764667
Longitude 135.375333
Altitude 30.5
SSID -A
GPS-A Symbol Car
Course 123
Speed 23.5
GPS Time Stamp 12:00:00
GPS Message Osaka City/IC-7100 Caller is "DV-G": Records the GPS message
RX Transmission and reception
12/23/2012 Date and time the call was started.
13:51:48
( When Duplex is set, the frequencies of the called are displayed.)
DV Operating mode (All mode)
34.764667 Your latitude (unit: degree) +: North latitude, –: South latitude
50.5 Your altitude (unit: m) Records to one decimal place.
(Blank) TX output power level
S0 The relative signal strength of the receive signal (in sixteen levels)
JP3YHJ A Repeater call sign (DV mode only)
(Blank) TX Call sign (DV mode only)
JA3YUA A RX Call sign (DV mode only)
34.764667 Caller's latitude, if sent. (unit: degree) +: North latitude, –: South latitude
Records only when you receive in the DV mode.
135.375333 Caller's longitude, if sent. (unit: degree) +: East longitude, –: West longitude
Records only when you receive in the DV mode.
30.5 Caller's altitude, if sent. (unit: m)
Records only when you receive in the DV mode.
Example
RX Frequency
Operating mode (DV is fixed)
Call sign of the caller station
Note after the call sign
Call sign of the called station
Access repeater call sign of the caller station or the gateway repeater call sign
of your local area repeater.
Access repeater call sign of the called station
Message included in the received call (up to 20 characters)
Normal: blank, Uplink: RPT UP
Access repeater reply: "UR?" or "RPT?"
Date and time the call was received
Depending on the setting, the format may differ.
BK call: "*", Normal call: Blank
EMR call: "*", Normal call: Blank
Caller's latitude, if sent. (unit: degree) +: North latitude, –: South latitude
Caller's longitude, if sent. (unit: degree) +: East longitude, –: West longitude
Caller's altitude, if sent. (unit: m)
Records one of (-0), -1 to -15 and -A to -Z.
Icon: Converts to text
None: Code
Caller's course (unit: degree)
Caller's speed (unit: km/h) Records to one decimal place.
Time data that the caller station acquires the position data
Caller is "DV-A: Records the GPS-A comment
Description
Description
17-17
