Icom IC-7100 Advanced Instructions page 361

Previous view
20
CONTROL COMMAND
Remote jack (CI-V) information
D
Command table (Continued)
Cmd. Sub cmd. Data
1A 05 0116 00/01
0117 00/01
0118 00/01
0119 00/01
0120 20000101 to
20991231
0121 0000 to
2359
0122 00/01
0123 see p. 20-13 Send/read the UTC offset setting
0124 00/01
0125 00 to 04
0126 00 to 10
0127 00 to 14
0128 00/01
0129 00 to 04
0130 01 to 04
0131 0001 to
9999
0132 0000 to
0255
0133 00/01
0134 01 to 60
0135 28 to 45
0136 00 to 03
0137 00/01
0138 00 to 02
Description
Send/read the Opening Message
(00=OFF, 01=ON)
Send/read the Power ON Check
setting
(00=OFF, 01=ON)
Send/read the Display Language
(00=English, 01=Japanese)
Send/read the System Language
(00=English, 01=Japanese)
Send/read the date setting
(20000101=2000/01/01 to
20991231=2099/12/31)
Send/read the time setting
(0000(0:00) to 2359(23:59))
Send/read the GPS time correction
setting
(00=OFF, 01=Auto)
Send/read the clock display mode
(00=LOCAL, 01=UTC)
Send/read the Auto Power OFF
function setting
(00=OFF, 01=30 min., 02=60 min.,
03=90 min., 04=120 min.)
Send/read the compression level
(00=0 to 10=10)
Send/read the repeat interval to
transmit the recorded voice audio
(00=1 sec. to 14=15 sec.)
Send/read the TX voice audio moni-
tor function setting
(00=OFF, 01=ON)
Send/read the numbering system
used for contest (serial) numbers
(00=Normal, 01=190 ANO,
02=190 ANT, 03=90 NO,
04=90 NT)
Send/read the count-up trigger
channel
(01=M1 to 04=M4)
Send/read the current contest serial
number
(0001=1 to 9999=9999)
Send/read the CW sidetone level
(0000=0% to 0255=100%)
Send/read the CW sidetone level
limit setting
(00=OFF, 01=ON)
Send/read the CW keyer repeat
time
(01=1 sec. to 60=60 sec.)
Send/read the CW keyer dot/dash
ratio
(28=1:1:2.8 to 45=1:1:4.5)
Send/read the CW Rise time setting
(00=2 msec, 01=4 msec, 02=6
msec, 03=8 msec)
Send/read the paddle polarity
setting
(00=Normal, 01=Reverse)
Send/read the keyer type setting
(00=Straight, 01=BUG-Key,
02=ELEC-Key)
Cmd. Sub cmd. Data
1A 05 0139 00/01
0140 00/01
0141 00 to 02
0142 00 to 02
0143 00/01
0144 00/01
0145 00/01
0146 00/01
0147 00/01
0148 00/01
0149 00/01
0150 00/01
0151 00/01
0152 00 to 03
0153 00/01
0154 00/01
0155 00 to 10
0156 00 to 06
0157 00/01
0158 0000 to
0255
0159 00 to 09
0160 0000 to
0255
0161 00 to 15
20-8
Description
Send/read Mic. up/down keyer
setting
(00=OFF, 01=ON)
Send/read the Twin Peak Filter
setting
(00=OFF, 01=ON)
Send/read the RTTY mark fre-
quency
(00=1275 Hz, 01=1615 Hz,
02=2125 Hz)
Send/read the RTTY shift width
(00=170 Hz, 01=200 Hz,
02=425 Hz)
Send/read the RTTY keying polarity
(00=Normal, 01=Reverse)
Send/read the RTTY decode USOS
setting
(00=OFF, 01=ON)
Send/read the RTTY decode new
line code setting
(00=CR,LF,CR+LF, 01=CR+LF)
Send/read the RTTY TX USOS
setting
(00=OFF, 01=ON)
Send/read the RTTY Decode Log
setting
(00=OFF, 01=ON)
Send/read the RTTY Decode Log
file type
(00=Text, 01=HTML)
Send/read the RTTY Decode Log
Time Stamp setting
(00=OFF, 01=ON)
Send/read the RTTY Decode Log
Time Stamp (Time)
(00=Local, 01=UTC)
Send/read the RTTY Decode Log
Time Stamp (Frequency)
(00=OFF, 01=ON)
Send/read the DTMF Speed setting
(00=100 msec., 01=200 msec.,
02=300 msec., 03=500 msec.)
Send/read the Scan speed setting
(00=Slow, 01=Fast)
Send/read the Scan resume setting
(00=OFF, 01=ON)
Send/read the Scan pause timer
setting
(00=2 sec. to 09=20 sec.,
10=HOLD)
Send/read the Scan resume timer
(00=0 sec. to 05=5 sec., 6=HOLD)
Send/read the Dial function during
a scan
(00=OFF, 01=Up/Down)
Send/read the NB level
(0000=0% to 0255=100%)
Send/read the NB depth
(00=1 to 09=10)
Send/read the NB width
(0000=1 to 0255=100)
Send/read the NR level for other
than the DR mode
(00=0 to 15=15)
