CONTROL COMMAND
Remote jack (CI-V) information
D
Command table (Continued)
Cmd.
Sub cmd.
Data
19
00
1A
00
see p. 20-16 Send/read the Memory channel
01
see p. 20-12 Send/read the Band stacking regis-
02
see p. 20-13 Send/read the Memory keyer
03
00 to 49
04
00 to 13
05
0001
00/01
0002
0000 to
0255
0003
0004
00/01
0005
00/01
0006
00 to 03
0007
00 to 02
0008
00 to 05
0009
00 to 05
0010
00 to 05
0011
00 to 05
0012
00 to 05
0013
00 to 05
0014
00/01
Description
Read the transceiver ID
contents
ter contents
contents*
Send/read the selected filter width
(AM: 00=200 Hz to 49=10 kHz;
other than AM modes: 00=50 Hz to
40/31=3600 Hz/2700 Hz)
Send/read the selected AGC time
constant
(00=OFF, AM: 01=0.3 sec. to
13=8.0 sec., SSB/CW/RTTY:
01=0.1 sec. to 13=6.0 sec.)
Send/read the TX Monitor function
setting
(00=OFF, 01=ON)
Send/read the TX Monitor level
(0000=0% to 0255=100%)
Send/read the Beep level
(0000=0% to 0255=100%)
Send/read the Beep level limit
setting
(00=OFF, 01=ON)
Send/read the Confirmation beep
setting
(00=OFF, 01=ON)
Send/read the Band edge beep
setting
(00=OFF, 01=ON(Default),
02=ON(User),
03=ON(User & TX Limit))
Send/read the RF/SQL Control
setting
(00=Auto, 01=SQL, 02=RF+SQL)
Send/read the TX Delay setting
(HF)
(00=OFF, 01=10ms, 02=15ms,
03=20ms, 04=25ms, 05=30ms)
Send/read the TX Delay setting
(50M)
(00=OFF, 01=10ms, 02=15ms,
03=20ms, 04=25ms, 05=30ms)
Send/read the TX Delay setting
(70M)
(00=OFF, 01=10ms, 02=15ms,
03=20ms, 04=25ms, 05=30ms)
Send/read the TX Delay setting
(144M)
(00=OFF, 01=10ms, 02=15ms,
03=20ms, 04=25ms, 05=30ms)
Send/read the TX Delay setting
(430M)
(00=OFF, 01=10ms, 02=15ms,
03=20ms, 04=25ms, 05=30ms)
Send/read the Time-Out Timer
setting
(0=OFF, 1=3 min., 2=5 min., 3=10
min., 4=20 min., 5=30 min.)
Send/read the PTT Lock function
setting
(00=OFF, 01=ON)
Cmd.
Sub cmd.
Data
1A
05
0015
00/01
0016
see p. 20-13 Send/read the Split offset frequency
0017
00/01
0018
see p. 20-13 Send/read the Duplex offset fre-
0019
00/01
0020
00 to 02
0021
00/01
0022
00/01
0023
00
01
0024
00/01
0025
00/01
0026
00/01
0027
00 to 02
0028
00/01
0029
00 to 02
0030
00 to 02
0031
00/01
0032
00/01
0033
00/01
0034
00/01
* The counter can be inserted into only one channel. Before inserting the
counter, be sure to clear the counter on another channel.
20-5
Description
Send/read the Quick Split function
setting
(00=OFF, 01=ON)
Send/read the Split Lock function
setting
(00=OFF, 01=ON)
quency
Send/read the One Touch Repeater
setting
(00=DUP-, 01=DUP+)
Send/read the Auto Repeater set-
ting
(0=OFF, 1=ON(DUP) (for USA
version) or ON (for Korea ver-
sion), 2=ON(DUP,TONE)(for USA
version)
Send/read the Tuner Auto Start
setting
(00=OFF, 01=ON)
Send/read the PTT Tune setting
(00=OFF, 01=ON)
Send/read the Manual selection for
the [TUNER] Switch function.
Send/read the Auto selection for the
[TUNER] Switch function.
Send/read [SPEECH/LOCK] key
function setting
(00=Push: SPEECH, Hold down:
LOCK), 01=Push: LOCK, Hold
down: SPEECH)
Send/read the Lock function setting
(00=MAIN DIAL, 01=PANEL)
Send/read the number of memo
pad channels
(00=5CH, 01=10CH)
Send/read the Auto TS setting for
the Dial
(00=OFF, 01=LOW, 02=HIGH)
Send/read the microphone Up/
Down speed setting
(00=Slow, 01=Fast)
Send/read the Notch function set-
ting for SSB mode
(00=Auto, 01=Manual,
02=Auto/Manual)
Send/read the Notch function set-
ting for AM mode
(00=Auto, 01=Manual,
02=Auto/Manual)
Send/read the SSB/CW Synchro-
nous Tuning function setting
(00=OFF, 01=ON)
Send/read the CW normal side
setting
(00=LSB, 01=USB)
Send/read the voice 1st menu
(00=VOICE-Root, 01=VOICE-TX)
Send/read the keyer 1st menu
(00=KEYER-Root,
01=KEYER-SEND)
