CONTROL COMMAND
Remote jack (CI-V) information
D
Command table (Continued)
Cmd. Sub cmd. Data
1A 05 0074 see p. 20-11 Send/read the WIDE SSB TX
0075 see p. 20-11 Send/read the MID SSB TX band-
0076 see p. 20-11 Send/read the NARROW SSB TX
0077 00 to 10
0078 00 to 10
0079 00 to 10
0080 00 to 10
0081 00 to 10
0082 00 to 10
0083 00/01
0084 00/01
0085 0000 to
0255
0086 0000 to
0255
0087 0000 to
0255
0088 0000 to
0255
0089 0000 to
0255
0090 00 to 03
0091 00 to 03
0092 00/01
0093 00/01
0094 00/01
0095 00/01
Description
bandwidth
width
bandwidth
Send/read the AM TX tone (Bass)
level
(00=–5 to 10=+5)
Send/read the AM TX Tone (Treble)
level
(00=–5 to 10=+5)
Send/read the FM TX tone (Bass)
level
(00=–5 to 10=+5)
Send/read the FM TX Tone (Treble)
level
(00=–5 to 10=+5)
Send/read the DV TX tone (Bass)
level
(00=–5 to 10=+5)
Send/read the DV TX Tone (Treble)
level
(00=–5 to 10=+5)
Send/read the USB audio squelch
setting
(00=OFF (OPEN), 01=ON)
Send/read the ACC and USB
output setting
(00=AF, 01=IF)
Send/read the ACC and USB AF
output Level
(0000=0% to 0255=100%)
Send/read the ACC and USB IF
output Level
(0000=0% to 0255=100%)
Send/read the ACC modulation
level
(0000=0% to 0255=100%)
Send/read the DATA modulation
level
(0000=0% to 0255=100%)
Send/read the USB modulation
level
(0000=0% to 0255=100%)
Send/read the modulation input set-
ting in the DATA mode OFF
( 00=MIC, 01=ACC, 02=MIC,ACC,
03=USB)
Send/read the modulation input set-
ting in the DATA mode ON
( 00=MIC, 01=ACC, 02=MIC,ACC,
03=USB)
Send/read the external keypad set-
ting for VOICE
(00=OFF, 01=ON)
Send/read the external keypad set-
ting for Memory KEYER
(00=OFF, 01=ON)
Send/read the external keypad set-
ting for RTTY Memory
(00=OFF, 01=ON)
Send/read the CI-V transceive
setting
(00=OFF, 01=ON)
Cmd. Sub cmd. Data
1A 05 0096 00 to 02
0097 00 to 03
0098 00/01
0099 00/01
0100 00 to 04
0101 00 to 02
0102 00/01
0103 0000 to
0255
0104 0000 to
0255
0105 0000 to
0255
0106 00/01
0107 00/01
0108 00/01
0109 00 to 02
0110 00/01
0111 00/01
0112 00 to 02
0113 00/01
0114 00/01
0115 00/01
20-7
Description
Send/read the "USB2" (COM port)
function setting
( 00=OFF, 01=RTTY Decode,
02=DV Data)
Send/read the [DATA1] function
setting
( 00=OFF, 01=RTTY Decode,
02=DV Data, 03=GPS)
Send/read the GPS output setting
(00=OFF, 01=DATA1USB2)
Send/read the DV or GPS data
transfer speed
(00=4800 bps, 01=9600 bps)
Send/read the RTTY decode speed
( 00=300 bps, 01=1200 bps,
02=4800 bps, 03=9600 bps,
04=19200 bps)
Send/read the band setting for
the [ACC] socket's pin 7 (VSEND
usage)
(00=OFF, 01=UHF, 02=VHF/UHF)
Send/read the 9600bps Mode
setting
(00=OFF, 01=ON)
Send/read the LCD contrast setting
(0000=0% to 0255=100%)
Send/read the LCD Backlight set-
ting
(0000=0% to 0255=100%)
Send/read the Key Backlight setting
(0000=0% to 0255=100%)
Send/read the Meter Peak Hold
setting
(00=OFF, 01=ON)
Send/read the PBT shifting value
display setting while rotating [TWIN
PBT]
(00=OFF, 01=ON)
Send/read the IF filter width and
shifting value display setting when
the IF filter is switched
(00=OFF, 01=ON)
Send/read the RX Call sign display
setting
( 00=OFF, 01=AUTO, 02=Auto (RX
Hold))
Send/read the RX message display
setting
(00=OFF, 01=ON)
Send/read the RX position display
setting when the received Auto
Reply signal includes the position
(00=OFF, 01=ON)
Send/read the TX Call sign display
setting
( 00=OFF, 01=Your Call Sign,
02=My Call Sign)
Send/read the Scroll Speed setting
(00=Slow, 01=Fast)
Send/read the VOICE TX Name
Display setting
(00=OFF, 01=ON)
Send/read the KEYER Memory
Display setting
(00=OFF, 01=ON)
