SET MODE
Set mode items and Default settings (Continued)
NOTE: The default settings shown below in bold are for the USA version.
The default settings may differ, depending on your transceiver version.
Tone Control
RX
SSB
RX HPF/LPF
RX Bass
RX Treble
AM
RX HPF/LPF
RX Bass
RX Treble
FM
RX HPF/LPF
RX Bass
RX Treble
DV
RX HPF/LPF
RX Bass
RX Treble
WFM
RX Bass
RX Treble
CW
RX HPF/LPF
RTTY
RX HPF/LPF
TX
SSB
TX Bass
TX Treble
TBW (WIDE)
TBW (MID)
TBW (NAR)
AM
TX Bass
TX Treble
FM
TX Bass
TX Treble
DV
TX Bass
TX Treble
In this item, set the RX/TX tone control options.
---- – ----, 100~2000 – 500~2400
–5~0~+5
–5~0~+5
---- – ----, 100~2000 – 500~2400
–5~0~+5
–5~0~+5
---- – ----, 100~2000 – 500~2400
–5~0~+5
–5~0~+5
---- – ----, 100~2000 – 500~2400
–5~0~+5
–5~0~+5
–5~0~+5
–5~0~+5
---- – ----, 100~2000 – 500~2400
---- – ----, 100~2000 – 500~2400
–5~0~+5
–5~0~+5
100, 200, 300, 500 – 2500, 2700,
2800, 2900
100, 200, 300, 500 – 2500, 2700,
2800, 2900
100, 200, 300, 500 – 2500, 2700,
2800, 2900
–5~0~+5
–5~0~+5
–5~0~+5
–5~0~+5
–5~0~+5
–5~0~+5
17-7
Sets the high-pass filter or low-pass filter of the
receive audio.
Sets the bass level of the receive audio.
Sets the treble level of the receive audio.
Sets the high-pass filter or low-pass filter of the
receive audio.
Sets the bass level of the receive audio.
Sets the treble level of the receive audio.
Sets the high-pass filter or low-pass filter of the
receive audio.
Sets the bass level of the receive audio.
Sets the treble level of the receive audio.
Sets the high-pass filter or low-pass filter of the
receive audio.
Sets the bass level of the receive audio.
Sets the treble level of the receive audio.
Sets the bass level of the receive audio.
Sets the treble level of the receive audio.
Sets the high-pass filter or low-pass filter of the
receive audio.
Sets the high-pass filter or low-pass filter of the
receive audio.
Sets the bass level of the transmit audio.
Sets the treble level of the transmit audio.
Sets the lower and higher cut-off frequencies to
change the transmission passband width for the
wide setting.
Sets the lower and higher cut-off frequencies to
change the transmission passband width for the
mid setting.
Sets the lower and higher cut-off frequencies to
change the transmission passband width for the
narrow setting.
Sets the bass level of the transmit audio.
Sets the treble level of the transmit audio.
Sets the bass level of the transmit audio.
Sets the treble level of the transmit audio.
Sets the bass level of the transmit audio.
Sets the treble level of the transmit audio.
